Configurations
LA-481-01 Docking Station Case 16 (North America)*
LA-481-02 Docking Station Case (UK)*
LA-481-03 Docking Station Case 16 (Europe)*
LA-481-04 Docking Station Case 16 (Australia)*
*01, 02, 03, and 04 designation refers to international plug type (type B, G, C, and I) for the power supply.
Architectural Specs
The Docking Station Case 16 shall be capable of transporting, charging, programming and storing up to 16 ListenTALK products. The unit’s power supply shall accept an input voltage of 100 to 240AC, 50/60 H and shall deliver 12 VDC, 5 A at 60 watts to the case. The unit shall have a USB type B connection allowing programming via ListenTALK Software Suite. The unit shall have a pairing button allowing easy pairing and group formation. The unit shall have a status button allowing docked device status to be checked while remaining in the docking station pockets. The unit shall be capable of being locked. The unit shall have equivalent compliance with UL, CE, RCM and RoHS.
The LA-481 Docking Station Case 16 is specified.
